PALAZZETTI ECOFIRE pellet boiler stove model MIRELLA IDRO 9.3-15.4 kW

Description

PALAZZETTI ECOFIRE pellet boiler stove model MIRELLA IDRO 9.3-15.4 kW

DESCRIPTION

• Hermetic thermo-stove; it can draw combustion air directly from the outside; • painted steel cladding and cast iron top; • double door, an aesthetic one in curved glass and an internal technique with Balanced Door system; • brazier in thick cast iron; • ceramic glass (800°) with cleaning system; • firebox with fire tubes (no. 8) with turbulators; • large ash collection drawer; • Combustion Dynamic Control; • digital panel with touch control; • programmable operating time slots on a daily and weekly basis; • interface for integrated external thermostat or for connection to puffer tanks; • integrated hydraulic unit consisting of circulator, safety valve, closed expansion tank and pressure gauge; • predisposition for Connection Box; • integrated anti-condensation valve (commercial value 160 euros). AVAILABLE IN THE FOLLOWING COLOURS: WHITE – MOHKA – BLACK – RED

SPECIFICATIONS

MIRELLA boiler stove 9.3 kW Pellet
operation Nominal heat output 9.3 kW
Direct heat output to water 7.7 kW
Efficiency at nominal heat output 95.3 %
Max operating autonomy 33 h
Feed tank capacity 25 kg
Pellet hourly consumption 0.751 – 2.022 kg/h
Smoke outlet diameter ø 8 cm
Environmental performance level 5 Stars MIRELLA boiler stove 15.4 kW

Pellet
operation Nominal heat output 15.4 kW
Direct heat output to water 14.1 kW
Efficiency at nominal heat output 95.0 %
Operating autonomy max 25 h
Feed tank capacity 25 kg
Pellet hourly consumption 1 – 3,302 kg/h
Smoke outlet diameter ø 8 cm
Environmental performance level 4 Stars
