Original price was: 3819,00€.3704,43€Current price is: 3704,43€.
All products are shipped by express courier.
Shipping is free for all of Italy with the exception of islands and disadvantaged areas.
For disadvantaged islands and postal codes, you can request a quote on shipping costs by writing to vendita@xodostore.com
Three-sided wood-burning fireplace with natural convection characterized by a wide view of the fire. The door, entirely made of ceramic glass, can be opened with a stainless steel handle and a leaf to facilitate cleaning. Thick steel structure and combustion chamber and fire surface in ceramic refractory.
TK 03F
 |
|||
| TK 03F | |||
| Natural Convection | |||
| Quality class (D.M. 186 – 7/11/2017) |  |
||
| overall heat output (at the hearth) | 8.8 | Kw | |
| Certified | 7.5 | Kw | |
| CO measured (at 13% oxygen) | 0.09 | % | |
| yield | 85.2 | % | |
| Fuel | 2.7 | kg/h | |
| flow rate of fumes | 7 | g/s | |
| Flue | 221 | °C | |
| draught (vacuum at the chimney) | 11 | Pa | |
| Smoke | Ø 180 | Mm | |
| internal section of the chimney | Ø 180 | Mm | |
| Min. flue | 4.5 | m | |
| inlet ducts | Ø 15 | Cm | |
| Heatable surface with certified | 86 | *sqm | |
| net weight | 214 | Kg | |
| Weight with packaging | 234 | Kg | |
| * with the conditions shown in the General Catalogue | |||
product in possession of the requirements for achieving the “4 stars” Clean Air
