Name: Wood-burning fireplace with sliding rails MONTEGRAPPA LIGHT 06
Availability: InStock

Description

Wood-burning fireplace with sliding rails MONTEGRAPPA model LIGHT 06

NATURAL MODEL IN IMMEDIATE AVAILABILITY

Wood-burning fireplace that is characterized by the rectangular shape with an “extra-large” horizontal development. The door is entirely made of ceramic glass with a sliding mechanism and a flap opening for cleaning. Combustion chamber lined with CMtech®, refractory made with significant thicknesses; in the upper part the Catalyst-Flame Breaker is made of CMtech®2, a ceramic refractory.

LIGHT 06

Marking of compliance with European standards

European reference standard for inserts and fireplaces

European Directive for biomass domestic appliances: stoves, fireplaces and cookers (EU Regulation 2015/1185)

Technical data

Natural

power

USD

consumption

Mass

gas temperature

outlet pipe

height

air

power



	LIGHT 06N	LIGHT 06V
	Convection	ventilated
Quality class (D.M. 186 – 7/11/2017)
overall heat output (at the hearth)	18.1	17.5	Kw
Certified	15.0	15.0	Kw
CO measured (at 13% oxygen)	0.052	0.052	%
yield	82.5	85.5	%
Fuel	4.4	4.2	kg/h
flow rate of fumes	15.5	14.7	g/s
Flue	242	196	°C
draught (vacuum at the chimney)	12	12	Pa
Smoke	Ø 250	Ø 250	Mm
internal section of the chimney	Ø 25 / 25×25	Ø 25 / 25×25	Cm
Min. flue	5	5	m
inlet ducts	2 x Ø 15	2 x Ø 15	Cm
Heatable surface with certified	172	172	*sqm
net weight	289	306	Kg
Weight with packaging	316	335	Kg
* with the conditions shown in the General Catalogue
